GPM MG5028TS 40CR Steel 28T Motor Gear - Precision Replacement  [MG5028TS]

GPM MG5028TS 40CR Motor Gear Technical Summary

The GPM MG5028TS 40CR Steel Motor Gear is a precision engineered replacement made from hardened 40Cr carbon steel to extend service life and reduce tooth wear. The black hardening process increases surface hardness without altering critical dimensions, while the double kimi screw fixation method provides a stable mechanical joint for consistent torque transfer in demanding use.

Engineering Details

• Material: 40Cr Carbon Steel
• Tooth Count: 28T
• Motor Tooth Diameter: 5mm
• D-Shaped Motor Gear Hole
• Module: 1.0mm
• Total Thickness: 15mm
• Tooth Surface Thickness: 8mm
• Outer Diameter of Tooth Surface: 29.9mm

Packing includes

• Motor gear 28T – 1pc
• 4X5 Screw shaft – 2pcs
